In my last article, I stated that for practitioners (as opposed to theorists), the real prerequisite for machine learning is data analysis, not math.
One of the main reasons for making this statement, is that data scientists spend an inordinate amount of time on data analysis. The traditional statement is that data scientists “spend 80% of their time on data preparation.” While I think that this statement is essentially correct, a more precise statement is that you’ll spend 80% of your time on getting data, cleaning data, aggregating data, reshaping data, and exploring data using exploratory data analysis and data visualization. (From this point forward, I’ll use the term “data analysis” as a shorthand for getting data, reshaping it, exploring it, and visualizing it.)
And ultimately, the importance of data analysis applies not only to data science generally, but machine learning specifically.
The fact is, if you want to build a machine learning model, you’ll spend huge amounts of time just doing data analysis as a precursor to that process.
Moreover, you’ll use data analysis to explore the results of your model after you’ve applied an ML algorithm.
Additionally, in industry, you’ll also need to rely heavily on data visualization techniques to present the results after you’ve finalized them. This is one of the practical details of working as a data scientist that many courses and teachers never tell you about. Creating presentations to communicate your results will take large amounts of your time. And to create these presentations, you should rely heavily data visualization to communicate the model results visually.
Data analysis and data visualization are critical at almost every part of the machine learning workflow.
So, to get started with ML (and to eventually master it) you need to be able to apply visualization and analysis.
In this post, I’ll show you some of the basic data analysis and visualization techniques you’ll need to know to build a machine learning model.
One note before we get started: the problem that we’ll work through is just linear regression and we’ll be using an easy-to-use, off-the-shelf dataset. It’s a “toy problem,” which is intentional. Whenever you try to learn a new skill, it is extremely helpful to isolate different details of that skill.
The skill that I really want you to focus on here is data visualization (as it applies to machine learning).
We’ll also be performing a little bit of data manipulation, but it will be in service of analyzing and visualizing the data. We won’t be doing any data manipulation to “clean” the data.
So just keep that in mind. We’re working on a very simplified problem. I’m removing or limiting several other parts of the ML workflow so we can strictly focus on preliminary visualization and analysis for machine learning.
The first step almost of any analysis or model building effort is getting the data.
For this particular analysis, we’ll use a relatively “off the shelf” dataset that’s available in R within the MASS package.
data(Boston, package = "MASS")
The dataset contains data on median house price for houses in the Boston area. The variable that we’ll try to predict is the variable (median house price). The dataset has roughly a dozen other predictors that we’ll be investigating and using in our model.
As I already mentioned, the example we’ll be working through is a bit of a “toy” example, and as such, we’re working with a dataset that’s relatively “easy to use.” What I mean is that I’ve chosen this dataset because it’s easy to obtain and it doesn’t require much data cleaning.
However, keep in mind that in a typical business or industry setting, you’ll probably need to get your data from a database using SQL or possibly from a spreadsheet or other file.
Moreover, it’s very common for data to be “messy.” The data may have lots of missing values; variable names and class names that need to be changed; or other details that need to be altered.
Again, I’m intentionally leaving “data cleaning” out of this blog post for the sake of simplicity.
Just keep in mind that in many cases, you’ll have some data cleaning to do.
After getting the dataset, the next step in the model building workflow is almost always data visualization. Specifically, we’ll perform exploratory data analysis on the data to accomplish several tasks:
1. View data distributions
2. Identify skewed predictors
3. Identify outliers
Let’s begin our data exploration by visualizing the data distributions of our variables.
We can start by visualizing the distribution of our target variable, .
To do this, we’ll first use a basic histogram.
I strongly believe that the histogram is one of the “core visualization techniques” that every data scientists should master. If you want to be a great data scientist, and if you ultimately want to build machine learning models, then mastering the histogram is one of your “first steps.”
By “master”, I mean that you should be able to write this code “with your eyes closed.” A good data scientist should be able to write the code to create a histogram (or scatterplot, or line chart ….) from scratch, without any reference material and without “copying and pasting.” You should be able to write it from memory almost as fast as you can type.
One of the reasons that I believe the histogram is so important is because we use it frequently in this sort of exploratory data analysis. When we’re performing an analysis or building a model, it is extremely common to examine the distribution of a variable. Because it’s so common to do this, you should know this technique cold.
Here’s the code to create a histogram of our target variable .
############################ # VISUALIZE TARGET VARIABLE ############################ require(ggplot2) #~~~~~~~~~~~ # histogram #~~~~~~~~~~~ ggplot(data = Boston, aes(x = medv)) + geom_histogram()
If you don’t really understand how this code works, I’d highly recommend that you read my blog post about how to create a histogram with ggplot2. That post explains how the histogram code works, step by step.
Let’s also create a density plot .
Here’s the exact code to create a density plot .
#~~~~~~~~~~~~~~ # density plot #~~~~~~~~~~~~~~ ggplot(data = Boston, aes(x = medv)) + stat_density()
The density plot is essentially a variation of the histogram. The code to create a density plot is essentially identical to the code for a histogram, except that the second line is changed from to . Speaking in terms of ggplot2 syntax, we’re replacing the histogram geom with a statistical transformation.
If you’ve been working with data visualization for a while, you might want to learn a little bit about the differences between histograms and density plots, and how we use them. This is more of an intermediate data visualization topic, but it’s relevant to this blog post on ‘data visualization for machine learning’, so I’ll mention it.
Between histograms and density plots, some people strongly prefer histograms. The primary reason for this is that histograms tend to “provide better information on the exact location of data” (which is good for detecting outliers). This is true in particular when you use a relatively larger number of histogram bins; a histogram with a sufficiently large number of bins can show you peaks and unusual data details a little better, because it doesn’t smooth that information away. (Density plots and histograms with a small number of bins can smooth that information out too much.) So, when we’re visualizing a single variable, the histogram might be the better option.
However, when we’re visualizing multiple variables at a time, density plots are easier to work with. If you attempt to plot several histograms at the same time by using a small multiple chart, it can be very difficult to select a single binwidth that properly displays all of your variables. Because of this, density plots are easier to work with when you’re visualizing multiple variables in a small multiple chart. Density plots show the general shape of the data and we don’t have to worry about choosing the number of bins.
Ok, so having plotted the distribution of our target variable, let’s examine the plots. We can immediately see a few important details:
1. It’s not perfectly normal.
This is one of the things we’re looking for when we visualize our data (particularly for linear regression). I’ll save a complete explanation of why we test for normality in linear regression and machine learning, but in brief, we are examining this because many machine learning techniques require normally distributed variables.
2. It appears that there may be a few minor outliers in the far right tail of the distribution. For the sake of simplicity, we’re not going to deal with those outliers here; we’ll be able to build a model (imperfect though it might be) without worrying about those outliers right now.
Keep in mind, however, that you’ll be looking for them when you plot your data, and in some cases, they may be problematic enough to warrant some action.
Now that we’ve examined our target variable, let’s look at the distributions of all of the variables in our dataset.
We’re going to visualize all of our predictors in a single chart, like this:
This is known as a small multiple chart (sometimes also called a “trellis chart”). Basically, the small multiple chart allows you to plot many charts in a grid format, side by side. It allows you to use the same basic graphic or chart to display different slices of a data set. In this case, we’ll use the small multiple to visualize different variables.
You might be tempted to visualize each predictor individually – one chart at a time – but that can get cumbersome and tedious very quickly. When you’re working with more than a couple of variables, the small multiple will save you lots of time. This is particularly true if you work with datasets with dozens, even hundreds of variables.
Although the small multiple is perfect for a task like this, we’ll have to do some minor data wrangling to use it.
To use the small multiple design to visualize our variables, we’ll have to manipulate our data into shape.
Before we reshape the data, let’s take a look at the data as it currently exists:
head(Boston)
Notice that the variables are currently located as columns of the data frame. For example, the variable is the first column. This is how data is commonly formatted in a data frame; typical data frames have variables as columns, and data observations as rows. This format is commonly called “wide-format” data.
However, to create a “small multiple” to plot all of our variables, we need to reshape our data so that the variables are along the rows; we need to reshape our data into “long-format.’
To do this, we’re going to use the function from the package. This function will change the shape of the data from wide-format to long-format.
require(ggplot2) require(reshape2) melt.boston <- melt(Boston) head(melt.boston)
After using , notice that the variable (which had been a column) is now dispersed along the rows of our reshaped dataset, . In fact, if you examine the whole dataset, all of our dataset features are now along rows.
Now that we’ve melted our data into long-format, we’re going to use ggplot2 to create a small multiple chart. Specifically, we’ll use to implement the small-multiple design.
ggplot(data = melt.boston, aes(x = value)) + stat_density() + facet_wrap(~variable, scales = "free")
So now that we’ve visualized the distributions of all of our variables, what are we looking for?
We’re looking primarily for a few things:
1. Outliers
2. Skewness
3. Other deviations from normality
Let’s examine skewness first (simply because that seems to be one of the primary issues with these features).
Just to refresh your memory, skewness is a measure of asymmetry of a data distribution.
You can immediately see that several of the variables are highly skewed .
In particular, , , , , and are highly skewed. Several of the others appear to have moderate skewness.
We’ll quickly confirm this by calculating the skewness:
#~~~~~~~~~~~~~~~~~~~~ # calculate skewness #~~~~~~~~~~~~~~~~~~~~ require(e1071) sapply(Boston, skewness)
To be clear, skewness can be a bit of a slippery concept, but note that a skewness of zero indicates a symmetrical distribution. Ideally, we’re looking for variables with a skewness of zero.
Also, a very rough rule of thumb is if the absolute value of skewness is above 1, then the variable has high skewness.
Looking at these numbers, a few of the variables have relatively low skewness, including , , and (although is much more symmetrical).
Part of the task of data exploration for ML is knowing what to do with the information uncovered in the data exploration process. That is, once you’ve identified potential problems and salient characteristics of your data, you need to be able to transform your data in ways that will make the machine learning algorithms work better. As I said previously, “data transformation” is a separate skill, and because we’re focusing on the pure “data exploration” process in this post, we won’t discussing data transformations. (Transformations are a big topic.)
Be aware, however, that in a common ML workflow, your learnings from EDA will serve as an input to the “data transformation” step of your workflow.
Let’s recap what we just did:
1. Plotted a histogram of our target variable using ggplot2
2. Reshaped our dataset using melt()
3. Plotted the variables using the small multiple design
4. Examined our variables for skewness and outliers
To be honest, this was actually an abbreviated list of things to do. We could also have looked at correlation, among other things.
This is more than enough to get you started though.
By now, you should have some indication of what skills you need to know to get started with practical machine learning in R:
1. Learn ggplot2
– master basic techniques like the histogram and scatterplot
– learn how to facet your data in ggplot2 to perform multivariate data exploration
2. Learn basic data manipulation. I’ll suggest dplyr (which we didn’t really use here), and also reshape.
In the next post, we’ll continue our use of data analysis in the ML workflow.
If you want to see part 2, sign up for the email list, and the next blog post will be delivered automatically to your inbox as soon as it’s published.
The post How to use data analysis for machine learning (example, part 1) appeared first on SHARP SIGHT LABS.
You need to know how well your algorithms perform on unseen data.
The best way to evaluate the performance of an algorithm would be to make predictions for new data to which you already know the answers. The second best way is to use clever techniques from statistics called resampling methods that allow you to make accurate estimates for how well your algorithm will perform on new data.
In this post you will discover how you can estimate the accuracy of your machine learning algorithms using resampling methods in Python and scikit-learn.
Let’s get started.
Evaluate the Performance of Machine Learning Algorithms in Python using Resampling
Photo by Doug Waldron, some rights reserved.
Resampling methods are demonstrated in this post using small code recipes in Python.
Each recipe is designed to be standalone so that you can copy-and-paste it into your project and use it immediately.
The Pima Indians onset of diabetes dataset is used in each recipe. This is a binary classification problem where all of the input variables are numeric. In each recipe it is downloaded directly from the UCI Machine Learning repository. You can replace it with your own dataset as needed.
Why can’t you train your machine learning algorithm on your dataset and use predictions from this same dataset to evaluate machine learning algorithms?
The simple answer is overfitting.
Imagine an algorithm that remembers every observation it is shown. If you evaluated your machine learning algorithm on the same dataset used to train the algorithm, then an algorithm like this would have a perfect score on the training dataset. But the predictions it made on new data would be terrible.
We must evaluate our machine learning algorithms on data that is not used to train the algorithm.
The evaluation is an estimate that we can use to talk about how well we think the algorithm may actually do in practice. It is not a guarantee of performance.
Once we estimate the performance of our algorithm, we can then re-train the final algorithm on the entire training dataset and get it ready for operational use.
Next up we are going to look at four different techniques that we can use to split up our training dataset and create useful estimates of performance for our machine learning algorithms:
We will start with the simplest method called Train and Test Sets.
The simplest method that we can use to evaluate the performance of a machine learning algorithm is to use different training and testing datasets.
We can take our original dataset, split it into two parts. Train the algorithm on the first part, make predictions on the second part and evaluate the predictions against the expected results.
The size of the split can depend on the size and specifics of your dataset, although it is common to use 67% of the data for training and the remaining 33% for testing.
This algorithm evaluation technique is very fast. It is ideal for large datasets (millions of records) where there is strong evidence that both splits of the data are representative of the underlying problem. Because of the speed, it is useful to use this approach when the algorithm you are investigating is slow to train.
A downside of this technique is that it can have a high variance. This means that differences in the training and test dataset can result in meaningful differences in the estimate of accuracy.
In the example below we split the data Pima Indians dataset into 67%/33% split for training and test and evaluate the accuracy of a Logistic Regression model.
# Evaluate using a train and a test set
import pandas
from sklearn import cross_validation
from sklearn.linear_model import LogisticRegression
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = pandas.read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
test_size = 0.33
seed = 7
X_train, X_test, Y_train, Y_test = cross_validation.train_test_split(X, Y, test_size=test_size, random_state=seed)
model = LogisticRegression()
model.fit(X_train, Y_train)
result = model.score(X_test, Y_test)
print("Accuracy: %.3f%%") % (result*100.0)
We can see that the estimated accuracy for the model was approximately 75%. Note that in addition to specifying the size of the split, we also specify the random seed. Because the split of the data is random, we want to ensure that the results are reproducible. By specifying the random seed we ensure that we get the same random numbers each time we run the code.
This is important if we want to compare this result to the estimated accuracy of another machine learning algorithm or the same algorithm with a different configuration. To ensure the comparison was apples-for-apples, we must ensure that they are trained and tested on the same data.
Accuracy: 75.591%
Cross validation is an approach that you can use to estimate the performance of a machine learning algorithm with less variance than a single train-test set split.
It works by splitting the dataset into k-parts (e.g. k=5 or k=10). Each split of the data is called a fold. The algorithm is trained on k-1 folds with one held back and tested on the held back fold. This is repeated so that each fold of the dataset is given a chance to be the held back test set.
After running cross validation you end up with k different performance scores that you can summarize using a mean and a standard deviation.
The result is a more reliable estimate of the performance of the algorithm on new data given your test data. It is more accurate because the algorithm is trained and evaluated multiple times on different data.
The choice of k must allow the size of each test partition to be large enough to be a reasonable sample of the problem, whilst allowing enough repetitions of the train-test evaluation of the algorithm to provide a fair estimate of the algorithms performance on unseen data. For modest sized datasets in the thousands or tens of thousands of records, k values of 3, 5 and 10 are common.
In the example below we use 10-fold cross validation.
# Evaluate using Cross Validation
import pandas
from sklearn import cross_validation
from sklearn.linear_model import LogisticRegression
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = pandas.read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
num_folds = 10
num_instances = len(X)
seed = 7
kfold = cross_validation.KFold(n=num_instances, n_folds=num_folds, random_state=seed)
model = LogisticRegression()
results = cross_validation.cross_val_score(model, X, Y, cv=kfold)
print("Accuracy: %.3f%% (%.3f%%)") % (results.mean()*100.0, results.std()*100.0)
You can see that we report both the mean and the standard deviation of the performance measure. When summarizing performance measures, it is a good practice to summarize the distribution of the measures, in this case assuming a Gaussian distribution of performance (a very reasonable assumption) and recording the mean and standard deviation.
Accuracy: 76.951% (4.841%)
You can configure cross validation so that the size of the fold is 1 (k is set to the number of observations in your dataset). This variation of cross validation is called leave-one-out cross validation.
The result is a large number of performance measures that can be summarized in an effort to give a more reasonable estimate of the accuracy of your model on unseen data. A downside is that it can be a computationally more expensive procedure than k-fold cross validation.
In the example below we use leave-one-out cross validation.
# Evaluate using Leave One Out Cross Validation
import pandas
from sklearn import cross_validation
from sklearn.linear_model import LogisticRegression
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = pandas.read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
num_folds = 10
num_instances = len(X)
loocv = cross_validation.LeaveOneOut(n=num_instances)
model = LogisticRegression()
results = cross_validation.cross_val_score(model, X, Y, cv=loocv)
print("Accuracy: %.3f%% (%.3f%%)") % (results.mean()*100.0, results.std()*100.0)
You can see in the standard deviation that the score has more variance than the k-fold cross validation results described above.
Accuracy: 76.823% (42.196%)
Another variation on k-fold cross validation is to create a random split of the data like the train/test split described above, but repeat the process of splitting and evaluation of the algorithm multiple times, like cross validation.
This has the speed of using a train/test split and the reduction in variance in the estimated performance of k-fold cross validation. You can also repeat the process many more times as need. A down side is that repetitions may include much of the same data in the train or the test split from run to run, introducing redundancy into the evaluation.
The example below splits the data into a 67%/33% train/test split and repeats the process 10 times.
# Evaluate using Shuffle Split Cross Validation
import pandas
from sklearn import cross_validation
from sklearn.linear_model import LogisticRegression
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = pandas.read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
num_samples = 10
test_size = 0.33
num_instances = len(X)
seed = 7
kfold = cross_validation.ShuffleSplit(n=num_instances, n_iter=num_samples, test_size=test_size, random_state=seed)
model = LogisticRegression()
results = cross_validation.cross_val_score(model, X, Y, cv=kfold)
print("Accuracy: %.3f%% (%.3f%%)") % (results.mean()*100.0, results.std()*100.0)
We can see that the distribution of the performance measure is on par with k-fold cross validation above.
Accuracy: 76.496% (1.698%)
The best advice is to experiment and find a technique for your problem that is fast and produces reasonable estimates of performance that you can use to make decisions. If in doubt, use 10-fold cross validation.
Python and scikit-learn are the rising platform among professional data scientists for applied machine learning.
PDF and Email Course.
Download your PDF containing all 14 lessons.
Get your daily lesson via email with tips and tricks.
In this post you discovered statistical techniques that you can use to estimate the performance of your machine learning algorithms, called resampling.
Specifically, you learned about:
Do you have any questions about resampling methods or this post? Ask your question in the comments and I will do my best to answer it.
Discover how to confidently step-through machine learning projects end-to-end in Python with scikit-learn in the new Ebook:
Machine Learning Mastery with Python
Take the next step with 16 self-study lessons covering data preparation, feature selection, ensembles and more.
Includes 3 end-to-end projects and a project template to tie it all together.
Ideal for beginners and intermediate levels.
Apply Machine Learning Like A Professional With Python
The post Evaluate the Performance of Machine Learning Algorithms in Python using Resampling appeared first on Machine Learning Mastery.
We all know the big machine learning projects out there: Scikit-learn, TensorFlow, Theano, etc. But what about the smaller niche projects that are actively developed, providing useful services to users? Here are 5 such projects.
The popular machine learning projects, in general, are popular because they either provide a wide range of needed services or they were the first (or possibly best) to provide a particular niche service to users. These popular projects include Scikit-learn, TensorFlow, Theano, MXNet (maybe?), Weka (formerly), and so on. Depending on the particular ecosystem(s) you work in, and on your machine learning goals, the projects which you consider popular may differ slightly; however, they all share the similarity that they provide services to a large base of users.
But there are all sorts of smaller machine learning projects out there that people are building and using: pipelines, wrappers, high-level APIs, cleaners, etc. They provide both niche and flexible services, usually for smaller numbers of users, for all sorts of reasons. This post will present 5 such smaller projects for readers to familiarize themselves with.
I'm not necessarily suggesting you go out and try all (or any) of these; if there is some particular requirement you are looking to fill which you happen to find a corresponding tool for in this list, then by all means give it a try. The real value here, however, at least in my view, is checking out what the projects offer, how they are implemented, and what others are building to fit into their ecosystems. You might get some good ideas of where to take your own projects. But best case: something here fills a need perfectly and you solve a problem, thanks to the work the developers listed herein are doing.
There is no real criteria for these items, I'm sorry to report. They are simply a collection of interesting projects I have noted over the past few months and thought were promising enough to share with readers. Also note that I am firmly invested in the Python ecosystem, and so these tools have been discovered accordingly. I don't have any bias against any of the projects that R or C++ or any other particular environment has to offer (and may discover and share such projects in future posts); this list came together generically, however, based on my internet wanderings as I searched for useful tools.
So here they are: 5 machine learning projects you should definitely have a look at, in no particular order (but numbered like they are in order, because I like numbering things):
1. Deepy
Deepy is an extensible deep learning framework based on Theano. It provides a clean, high-level interface for components such as LSTMs, Batch Normalization, and Auto Encoders. Deepy clearly aims for simplicity, and its documentation and examples aim for the same. It also has a sister project, which uses Deepy to implement Deep Recurrent Attentive Writer (DRAW) generative models.
For an example of Deepy's simplicity and cleanliness, here's an example of a multi-layer model with dropout, from the project's Github:
# A multi-layer model with dropout for MNIST task. from deepy import * model = NeuralClassifier(input_dim=28*28) model.stack(Dense(256, 'relu'), Dropout(0.2), Dense(256, 'relu'), Dropout(0.2), Dense(10, 'linear'), Softmax()) trainer = MomentumTrainer(model) annealer = LearningRateAnnealer(trainer) mnist = MiniBatches(MnistDataset(), batch_size=20) trainer.run(mnist, controllers=[annealer])
You may have even heard of Deepy already; its Github repo has 305 stars and has been forked 51 times, as of this writing. The project is a decent exemplar of high-level deep learning APIs and wrappers that are becoming widespread (or seem to be). Deepy is authored by Raphael Shu.
2. MLxtend
Sebastian Raschka has put together MLxtend, something he is quick to point out is a work in progress, but is also something which attempts to tick a number of different boxes. MLxtend is a collection of useful tools and extensions for machine learning tasks.
Sebastian shared the following with me, regarding the project, how it came to be, and its goals:
Essentially, it's just a collection of useful tools and reference implementations related to ML and data science in general. Why did I come up with it? There are a couple of reasons:
- Implementations of algorithms that I couldn't find anywhere else (e.g., the Sequential Feature Selection algorithms, the Majority Voting Classifier, the Stacking estimators, plotting decision regions, ...)
- Implementations for teaching purposes (logistic regression, softmax regression, multi-layer perceptron, PCA, kernel PCA...); these impl. focus on code readability rather than pure efficiency
- Wrappers for convenience: tensorflow softmax regression and multi-layer perceptrons, column-wise standardization for pandas data frames
This is essentially a library of commonly-used general machine learning functions that Sebastian has written and frequently uses. Additionally, Sebastian really likes to code, and thought that if he were to offer this "zoo" of different things (as he refers to it) up to others that he may keep the code "tidier" than usual.
Many of the implemented functions share similarities with scikit-learn's API, but future addition functionality will not necessarily be restricted by this. The big takeaway here: Sebastian promises that there is much more to come... so stay tuned. There's a good chance that any feature or novel algorithm that Sebastian plays with will end up being packaged in MLxtend.
3. datacleaner
datacleaner is the work of researcher Randal Olson, who is also responsible for the fantastic TPOT machine learning pipeline project. Olson bills Data Cleaner as a "Python tool that automatically cleans data sets and readies them for analysis." He is quick to declare that it is not magic, but also points out what it can do:
What datacleaner will do is save you a ton of time encoding and cleaning your data once it's already in a format that pandas DataFrames can handle.
datacleaner is a work in progress, but is currently capable of handling the following regular (and time-consuming) data cleaning operations: optionally drops rows with missing values; replaces missing values with either mode or median, on a column by column basis; encodes non-numerical variables with numerical equivalents. Randal tells us that he is looking for contributors, especially from those with more ideas on what data cleaning operations datacleaner could perform in an automated fashion.
Randal has an attention to detail that anyone who reads his blog or his Github repos already knows, and the concise documentation for this project is no exception. I have been using datacleaner recently, and so far it delivers on its promises.
4. auto-sklearn
auto-sklearn is automated machine learning for the Scikit-learn environment.
auto-sklearn frees a machine learning user from algorithm selection and hyperparameter tuning. It leverages recent advantages in Bayesian optimization, meta-learning and ensemble construction. Learn more about the technology behind auto-sklearn by reading this paper published at the NIPS 2015.
Its documentation is quite thorough, and the repo includes a few concise examples. I have, admittedly, not used it yet, but many others have; it has collected nearly 400 stars on Github. Given my propensity for Scikit-learn, I imagine I will try this out in the near future.
auto-sklearn is developed mainly by the Machine Learning for Automated Algorithm Design group at the University of Freiburg.
5. Deep Mining
Deep Mining is a machine learning pipeline auto-tuner, coming to us from Sebastien Dubois of the CSAIL lab at MIT. From the repo:
This software will test iteratively, and smartly, some hyperparameter sets in order to find as quickly as possible the best ones to achieve the best classification accuracy that a pipeline can offer.
Deep Mining does not seem to be a well-known project, given its relatively modest number of repo stars; however, given that it comes out of CSAIL, and has development activity within the past month, it may be worth benchmarking this against other similar automated pipeline tools. It comes with a few examples, and its usage seems to be straightforward.
More on the methods used:
The folder GCP-HPO contains all the code implementing the Gaussian Copula Process (GCP) and a hyperparameter optimization (HPO) technique based on it. Gaussian Copula Process can be seen as an improved version of the Gaussian Process, that does not assume a Gaussian prior for the marginal distributions but lies on a more complex prior. This new technique is proved to outperform GP-based hyperparameter optimization, which is already far better than the randomized search.
A paper on the GCP approach is forthcoming.
Related:
The data features that you use to train your machine learning models have a huge influence on the performance you can achieve.
Irrelevant or partially relevant features can negatively impact model performance.
In this post you will discover automatic feature selection techniques that you can use to prepare your machine learning data in python with scikit-learn.
Let’s get started.
Feature Selection For Machine Learning in Python
Photo by Baptiste Lafontaine, some rights reserved.
Feature selection is a process where you automatically select those features in your data that contribute most to the prediction variable or output in which you are interested.
Having irrelevant features in your data can decrease the accuracy of many models, especially linear algorithms like linear and logistic regression.
Three benefits of performing feature selection before modeling your data are:
You can learn more about feature selection with scikit-learn in the article Feature selection.
This section lists 4 feature selection recipes for machine learning in Python
This post contains recipes for feature selection methods.
Each recipe was designed to be complete and standalone so that you can copy-and-paste it directly into you project and use it immediately.
Recipes uses the Pima Indians onset of diabetes dataset to demonstrate the feature selection method. This is a binary classification problem where all of the attributes are numeric.
Statistical tests can be used to select those features that have the strongest relationship with the output variable.
The scikit-learn library provides the SelectKBest class that can be used with a suite of different statistical tests to select a specific number of features.
The example below uses the chi squared (chi^2) statistical test for non-negative features to select 4 of the best features from the Pima Indians onset of diabetes dataset.
# Feature Extraction with Univariate Statistical Tests (Chi-squared for classification) import pandas import numpy from sklearn.feature_selection import SelectKBest from sklearn.feature_selection import chi2 # load data url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] dataframe = pandas.read_csv(url, names=names) array = dataframe.values X = array[:,0:8] Y = array[:,8] # feature extraction test = SelectKBest(score_func=chi2, k=4) fit = test.fit(X, Y) # summarize scores numpy.set_printoptions(precision=3) print(fit.scores_) features = fit.transform(X) # summarize selected features print(features[0:5,:])
You can see the scores for each attribute and the 4 attributes chosen (those with the lowest scores): plas, test, mass and age.
[ 111.52 1411.887 17.605 53.108 2175.565 127.669 5.393 181.304] [[ 148. 0. 33.6 50. ] [ 85. 0. 26.6 31. ] [ 183. 0. 23.3 32. ] [ 89. 94. 28.1 21. ] [ 137. 168. 43.1 33. ]]
The Recursive Feature Elimination (or RFE) works by recursively removing attributes and building a model on those attributes that remain.
It uses the model accuracy to identify which attributes (and combination of attributes) contribute the most to predicting the target attribute.
You can learn more about the RFE class in the scikit-learn documentation.
The example below uses RFE with the logistic regression algorithm to select the top 3 features. The choice of algorithm does not matter too much as long as it is skillful and consistent.
# Feature Extraction with RFE
from pandas import read_csv
from sklearn.feature_selection import RFE
from sklearn.linear_model import LogisticRegression
# load data
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
# feature extraction
model = LogisticRegression()
rfe = RFE(model, 3)
fit = rfe.fit(X, Y)
print("Num Features: %d") % fit.n_features_
print("Selected Features: %s") % fit.support_
print("Feature Ranking: %s") % fit.ranking_
You can see that RFE chose the the top 3 features as preg, pedi and age. These are marked True in the support_ array and marked with a choice “1” in the ranking_ array.
Num Features: 3 Selected Features: [ True False False False False True True False] Feature Ranking: [1 2 3 5 6 1 1 4]
Principal Component Analysis (or PCA) uses linear algebra to transform the dataset into a compressed form.
Generally this is called a data reduction technique. A property of PCA is that you can choose the number of dimensions or principal component in the transformed result.
In the example below, we use PCA and select 3 principal components.
Learn more about the PCA class in scikit-learn by reviewing the PCA API. Dive deeper into the math behind PCA on the Principal Component Analysis Wikipedia article.
# Feature Extraction with PCA
import numpy
from pandas import read_csv
from sklearn.decomposition import PCA
# load data
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
dataframe = read_csv(url, names=names)
array = dataframe.values
X = array[:,0:8]
Y = array[:,8]
# feature extraction
pca = PCA(n_components=3)
fit = pca.fit(X)
# summarize components
print("Explained Variance: %s") % fit.explained_variance_ratio_
print(fit.components_)
You can see that the transformed dataset (3 principal components) bare little resemblance to the source data.
Explained Variance: [ 0.88854663 0.06159078 0.02579012]
[[ -2.02176587e-03 9.78115765e-02 1.60930503e-02 6.07566861e-02
9.93110844e-01 1.40108085e-02 5.37167919e-04 -3.56474430e-03]
[ 2.26488861e-02 9.72210040e-01 1.41909330e-01 -5.78614699e-02
-9.46266913e-02 4.69729766e-02 8.16804621e-04 1.40168181e-01]
[ -2.24649003e-02 1.43428710e-01 -9.22467192e-01 -3.07013055e-01
2.09773019e-02 -1.32444542e-01 -6.39983017e-04 -1.25454310e-01]]
Bagged decision trees like Random Forest and Extra Trees can be used to estimate the importance of features.
In the example below we construct a ExtraTreesClassifier classifier for the Pima Indians onset of diabetes dataset. You can learn more about the ExtraTreesClassifier class in the scikit-learn API.
# Feature Importance with Extra Trees Classifier from pandas import read_csv from sklearn.ensemble import ExtraTreesClassifier # load data url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] dataframe = read_csv(url, names=names) array = dataframe.values X = array[:,0:8] Y = array[:,8] # feature extraction model = ExtraTreesClassifier() model.fit(X, Y) print(model.feature_importances_)
You can see that we are given an importance score for each attribute where the larger score the more important the attribute. The scores suggest at the importance of plas, age and mass.
[ 0.11070069 0.2213717 0.08824115 0.08068703 0.07281761 0.14548537 0.12654214 0.15415431]
Python and scikit-learn are the rising platform among professional data scientists for applied machine learning.
PDF and Email Course.
Download your PDF containing all 14 lessons.
Get your daily lesson via email with tips and tricks.
In this post you discovered feature selection for preparing machine learning data in Python with scikit-learn.
You learned about 4 different automatic feature selection techniques:
If you are looking for more information on feature selection, see these related posts:
Do you have any questions about feature selection or this post? Ask your questions in the comment and I will do my best to answer them.
Discover how to confidently step-through machine learning projects end-to-end in Python with scikit-learn in the new Ebook:
Machine Learning Mastery with Python
Take the next step with 16 self-study lessons covering data preparation, feature selection, ensembles and more.
Includes 3 end-to-end projects and a project template to tie it all together.
Ideal for beginners and intermediate levels.
Apply Machine Learning Like A Professional With Python
The post Feature Selection For Machine Learning in Python appeared first on Machine Learning Mastery.
Matthew Leonawicz
Here I share R code I used to produce animated great circle arcs on top of a rotating 3D Earth. The code is not entirely reproducible but you should be able to use what is shared here to create your own video frames given your unique data and computing environment and resources.
The WordPress blog is not the most elegant for displaying lots of code so go to the original full post.
When I make great circle animations, at the core of the process is always an R function that transforms a series of coordinates describing points along a great circle arc into multiple series of great circle arc segments. The goal is simple: plot a series of line segments, saving each plot as a subsequent still frame, rather than plotting the original entire arc as a single plot. The input is generally a data table (much faster to work with than a data frame if you have a lot of data) with longitude and latitude columns where the coordinates in each row describe a subsequent point along one of my paths. I also use a third column to provide a unique group ID for each path to keep them distinct.
Before getting to this process, here is some example code of how I formatted my data this way when using the geosphere package. Do not get bogged down in the details here. This is just an example for fuller context regarding my specific animation referenced above and I will not be focusing on it. Your data will be quite different. You will have to arrange it similarly, but obviously it will be in a different context.
As you can see below, all you need is a data frame with columns of longitude and latitude. I created a SpatialPoints object from these. In my case I wanted to connect great circle arcs between each of two specific locations and all other locations in my data set. I marked the row indices for these two locations.
library(dplyr)
library(geosphere)
load("data.RData") # a data frame, d, containing 'long' and 'lat' columns
p <- SpatialPoints(cbind(d$long, d$lat), proj4string = CRS("+proj=longlat +datum=WGS84"))
idx1 <- 69 # great circles from coords in all other rows to coords in this row
idx2 <- 2648 # as above
get_paths <- function(x, idx, ...) {
gcInt <- function(x, x1, x2) {
x <- gcIntermediate(x[x1, ], x[x2, ], ...)
if (is.list(x)) {
x <- x %>% purrr::map2(c(x1, x1 + 0.5), ~data.frame(.x, .y)) %>%
bind_rows %>% setnames(c("long", "lat", "group"))
} else x <- data.frame(x, x1) %>% setnames(c("long", "lat", "group"))
x
}
purrr::map(setdiff(1:length(x), idx), ~gcInt(x, .x, idx)) %>% bind_rows
}
paths1 <- get_paths(p, idx1, addStartEnd = TRUE)
paths2 <- get_paths(p, idx2, addStartEnd = TRUE)
get_paths uses gcIntermediate from the geosphere package to obtain vectors of points defining great circle arcs between my two locations and all others. The resulting data frame has columns, long, lat, and group. I do not break the arcs at the dateline because I intend to draw them on a 3D globe, but if I were making a flat map I would do so. This is why the function handles the case of list output from gcIntermediate and adjusts the group ID by add 0.5 to one group.
Already more than enough details. You can see what I am going for though. Given my data, I want to end up with columns of longitude and latitude defining great circle arcs and broken out by unique group IDs. I show this because it's highly likely you will want to use geosphere in a similar way even if you won't be connecting points in the same way I am here.
Okay. You have your data in the right format. Now you want to break up your groups of great circle arcs into a larger number of nested subgroups of great circle arc segments. Let's get some basic prep out of the way.
Here are the packages I am using.
library(parallel)
library(gridExtra)
library(raster)
library(data.table)
library(dplyr)
library(ggplot2)
eb <- element_blank()
theme_blank <- theme(axis.line = eb, axis.text.x = eb, axis.text.y = eb, axis.ticks = eb,
axis.title.x = eb, axis.title.y = eb, legend.position = "none", panel.background = eb,
panel.border = eb, panel.grid.major = eb, panel.grid.minor = eb, plot.background = element_rect(colour = "transparent",
fill = "transparent"))
world <- map_data("world")
The ggplot2 theme will allow for plotting without all the extraneous stuff like margins and axes and colors I don't want on my Earth. The world map is an aside and has nothing to do with the great circles. I include it here because it was part of my animation. It will be used from plotting the backdrop of nation boundaries on the globe. Having these underneath the great circle animation is helpful for geographic visual orientation.
It's not clear yet, but the reason for including the raster package is because I also use a rasterized map layer of the earth's surface as the bottom layer underneath the nation boundaries. This is also an aside. It doesn't have anything to do with the great circle animation.
Yes, I am using R's built-in parallel package. I happen to be do at least the parallelized operations in this project on a Linux server with 32 CPUs and 260 GB RAM. I'm sorry to say but I can't help you if you want to do this on a local Windows pc for example. If you rework the code for a much more restrictive environment, depending on your data, you may find yourself waiting forever for your output. I just do not recommend doing this type of thing outside of a beefy server environment, at least if time is something you value.
Now, getting to the core of the process for real this time. Here is the actual function I used for the above animation to break great circle arcs into smaller segments.
df_segs <- function(d, seg.size, n.frames, replicates = 1, direction = "fixed") {
n <- nrow(d)
if (n < 3)
stop("Data not appropriate for this operation.")
if (seg.size < 3)
stop("Segment size too small.")
z <- round(runif(2, 2, seg.size))
z[z > n] <- n
n1 <- ceiling(diff(c((z[1] - z[2]), n))/z[1])
if (n.frames - n1 < 100)
stop("Insufficient frames")
offset <- sample(0:(n.frames - n1), replicates)
f <- function(k, d, n, n1, z, offset) {
ind2 <- z[1] * k
ind1 <- max(ind2 - z[2], 1)
if (ind2 > n)
ind2 <- n
d <- slice(d, ind1:ind2)
purrr::map(offset, ~mutate(d, group = ifelse(replicates == 1, group,
group + as.numeric(sprintf(".%d", k))), frameID = .x + k)) %>% bind_rows
}
if (direction == "reverse")
d <- mutate(d, long = rev(long), lat = rev(lat))
if (direction == "random" && rnorm(1) < 0)
d <- mutate(d, long = rev(long), lat = rev(lat))
d <- purrr::map(1:n1, ~f(.x, d, n, n1, z, offset)) %>% bind_rows %>% arrange(group,
frameID)
d
}
Going through the code, you can see it requires a minimum of 100 desired frames (which would make for quite a short video). You can tweak the maximum number of points in a segment. The minimum is always two. Each segment will vary in length uniformly between the minimum and maximum.
You can leave the data as is, with direction="fixed". This assumes the ordering of points/rows pertaining to each group is intended to show direction. Segments will be assembled in the same order. Alternatively, you can reverse or even randomize the order if it doesn’t matter for the given data.
This is just one example function. You can make your own if this one does not generate the type of segments or provide the kind of random variation in segments you would like.
Let’s go with 900 frames, which will result in about a 30 second video. Recall that in my case I had two different data sets. I combine them at the end of the above code snippet.
n.frames <- 900 set.seed(1) paths2 <- mutate(paths2, group = group + max(paths1$group)) paths <- bind_rows(paths1, paths2) %>% split(.$group)
Here I make the new table below. It has a subgroup ID column as well as a frame ID column. Group ID is now a decimal. To the left is the original great circle ID. To the right is the sequential segment ID. The latter is random and not all great circle arcs are broken up into the same number of segments. Some cover more rows of the table than others. They do not match up with the frame IDs and some recycling may be required if the number of desired frames is large enough.
paths <- mclapply(paths, df_segs, seg.size = 5, n.frames = n.frames, replicates = 1,
direction = "random", mc.cores = 32) %>% bind_rows
Alternatively, code like this will perform the same operation without using parallel processing. This may not be terribly problematic if the data set is not too large. I show this for comparison. But the need for parallel will be much greater in later steps.
paths <- paths %>% split(.$group) %>% purrr::map(~df_segs(.x, 5, n.frames, replicates = 1,
direction = "random")) %>% bind_rows
I use a rasterized bathymetry surface based on a csv file I downloaded by using the marmap package. I won’t discuss that here. Please see the marmap package for details and examples if this is important. It is straightforward to use that package to download a local copy of a subregion of the data (or the whole map) at a specified resolution.
The project_to_hemisphere function below (adapted from mapproj here) projects points onto the 3D earth and identifies which ones are within the hemisphere field of view given the centroid focal point. Identifying the half which are out of view in any given frame allows me to toss them out for some added efficiency. This is not actually a slow process. The conversion of coordinates is not complex or demanding. The slow part is drawing the high resolution orthographic projection maps with ggplot2.
d.bath <- read.csv("marmap_coord_-180;-90;180;90_res_10.csv") %>% data.table %>%
setnames(c("long", "lat", "z"))
r <- raster(extent(-180, 180, -90, 90), res = 1/6)
projection(r) <- "+proj=longlat +ellps=WGS84 +datum=WGS84 +no_defs"
r <- setValues(r, d.bath$z)
project_to_hemisphere <- function(lat, long, lat0, long0) {
hold <- c(lat, long)
x <- (pi/180) * c(lat, lat0, long - long0)
inview <- sin(x[1]) * sin(x[2]) + cos(x[1]) * cos(x[2]) * cos(x[3]) > 0
data.table(long = hold[2], lat = hold[1], inview = inview)
}
I want a 120-frame period, which is about four seconds of video, in which time I will complete one rotation of the earth. I define a sequence of longitude values, but this I allow to repeat for the total number of video frames, n.frames, specified earlier. Note that I keep the latitude focus (41 degrees) constant in this animation, but there is no reason this cannot vary as well. In the save_maps function below, there is a hard-coded 23.4-degree fixed orientation, but this is something that can also be made variable.
While the data we are interested in – the great circle arc segments – will plot sequentially over a series of 900 frames, both the nation boundaries and bathymetry surface map backdrops are constant so I only need to produce enough frames (120) for one rotation of each of those layers.
I split the path segments table on the frame ID. I will generate still frames in parallel.
In this animation I had originally chosen to aggregate my 10-minute resolution bathymetry surface from the marmap package because that resolution was a bit too fine and even in parallel it was taking an extremely long time for ggplot2 to draw the orthographic projection background maps. If I understand correctly, it is drawing a ton of tiny, filled polygons. It really grinds to a halt if you have a massive amount of them.
n.period <- 120
lon_seq <- rep(seq(0, 360, length.out = n.period + 1)[-(n.period + 1)], length = n.frames)
lat_seq <- rep(41, length(lon_seq))
paths <- paths %>% split(.$frameID)
d.bath.agg <- r %>% aggregate(2) %>% rasterToPoints %>% data.table %>% setnames(c("long",
"lat", "z"))
Next, in parallel across frames, I project my rasterized background map cells to the 3D surface and retain only the ones which are in view in a given frame as the earth spins. I use the full range of elevation data to retain a constant color palette mapping as cells at different extreme elevations move in and out of the field of view as the earth rotates. I store the range in z.range. I add a frame ID column. Finally I add a frame ID column for the nation boundaries table. The data is constant, but simply needs to be plotted 120 times in 3-degree shifts.
d.tiles <- mclapply(1:n.period, function(i, x, lon, lat) {
left_join(x, project_to_hemisphere(x$lat, x$long, lat[i], lon[i])) %>% filter(inview) %>%
dplyr::select(-inview) %>% mutate(frameID = i)
}, x = d.bath.agg, lat = lat_seq, lon = lon_seq, mc.cores = 32)
z.range <- purrr::map(d.tiles, ~range(.x$z, na.rm = TRUE)) %>% unlist %>% range
d.world <- purrr::map(1:n.period, ~mutate(world, frameID = .x))
I've showed the most important of two functions for making my great circle animation, df_segs, which I use to transformed a table of grouped rows of great circle arc coordinates into a much larger one with nested, grouped, sequential arc segments. The other critical function is save_maps.
Here I have generalized it a bit by adding a type argument. It is primarily used for iterating over the data for each frame in a table produced by df_segs (the default type="network"). This saves a map image of sequential great circle arc segments for each frame.
I added the options, type="maplines" and type="maptiles". The former is for the nation boundaries and the latter is for the rasterized map surface.
I call the function in parallel three times to cover each type of output. I generate 120 frames (one earth rotation in three-degree increments) of both the nation boundaries and the surface tiles. The latter takes by far the longest amount of time to process, far longer than even the 900 frames of network traffic itself.
save_maps <- function(x, lon_seq, lat_seq, col = NULL, type = "network", z.range = NULL) {
if (is.null(col))
col <- switch(type, network = c("#FFFFFF25", "#1E90FF25", "#FFFFFF",
"#1E90FF50"), maptiles = c("black", "steelblue4"), maplines = "white")
i <- x$frameID[1]
if (type == "network")
x.lead <- group_by(x, group) %>% slice(n())
g <- ggplot(x, aes(long, lat))
if (type == "maptiles") {
if (is.null(z.range))
z.range <- range(x$z, na.rm = TRUE)
g <- ggplot(x, aes(long, lat, fill = z)) + geom_tile() + scale_fill_gradientn(colors = col,
limits = z.range)
} else {
g <- ggplot(x, aes(long, lat, group = group))
if (type == "maplines")
g <- g + geom_path(colour = col)
if (type == "network")
g <- g + geom_path(colour = col[2]) + geom_path(colour = col[1]) +
geom_point(data = x.lead, colour = col[3], size = 0.6) + geom_point(data = x.lead,
colour = col[4], size = 0.3)
}
g <- g + theme_blank + coord_map("ortho", orientation = c(lat_seq[i], lon_seq[i],
23.4))
dir.create(outDir <- file.path("frames", type), recursive = TRUE, showWarnings = FALSE)
png(sprintf(paste0(outDir, "/", type, "_%03d.png"), i), width = 4 * 1920,
height = 4 * 1080, res = 300, bg = "transparent")
print(g)
dev.off()
NULL
}
mclapply(paths, save_maps, lon_seq, lat_seq, type = "network", mc.cores = 30)
mclapply(d.world, save_maps, lon_seq, lat_seq, type = "maplines", mc.cores = 30)
mclapply(d.tiles, save_maps, lon_seq, lat_seq, type = "maptiles", z.range = z.range,
mc.cores = 30)
For any project like this I simply drop each of the three sequences of sequentially numbered png files onto its own timeline track as a still image sequence in a standard video editor. I don't use R for this final step. While I could have plotted everything together on a single sequence of frames, it doesn't make sense to do so even when each sequence has equal length. This is because one sequence may take far longer to plot than another sequence. It is more efficient to make a different image sequence for separate layers and mix them in the editor afterward.
You might also notice the very high pixel dimensions of the png outputs. I do this in cases where I plan to zoom during an animation. The larger the image, the more I can zoom in without degradation. You can imagine that this generates a lot of data when you have thousands of frames and each image is several megabytes.
Instead, try something like this on a server with plenty of CPUs and RAM. Otherwise try it with a small data set. Due to the particular computing environment I used and the resources needed to process the frames in an efficient and timely fashion, it is impossible to share this example animation code in a completely reproducible fashion. However, you should be able to use df_segs or some alteration of it with a properly formatted input table to generate the type of table you would want to pass subsequently to save_maps (or some alteration of that as well).
That is the gist of this example and should be enough to get you started. Ultimately, you will have to adapt any code here to your unique data, its size and complexity, what exactly you want to do with it, and your available computing resources.
Artificial neural networks are a fascinating area of study, although they can be intimidating when just getting started.
There are a lot of specialized terminology used when describing the data structures and algorithms used in the field.
In this post you will get a crash course in the terminology and processes used in the field of multi-layer perceptron artificial neural networks. After reading this post you will know:
Let’s get started.
Crash Course In Neural Networks
Photo by Joe Stump, some rights reserved.
We are going to cover a lot of ground very quickly in this post. Here is an idea of what is ahead:
We will start off with an overview of multi-layer perceptrons.
The field of artificial neural networks is often just called neural networks or multi-layer perceptrons after perhaps the most useful type of neural network. A perceptron is a single neuron model that was a precursor to larger neural networks.
It is a field that investigates how simple models of biological brains can be used to solve difficult computational tasks like the predictive modeling tasks we see in machine learning. The goal is not to create realistic models of the brain, but instead to develop robust algorithms and data structures that we can use to model difficult problems.
The power of neural networks come from their ability to learn the representation in your training data and how to best relate it to the output variable that you want to predict. In this sense neural networks learn a mapping. Mathematically, they are capable of learning any mapping function and have been proven to be a universal approximation algorithm.
The predictive capability of neural networks comes from the hierarchical or multi-layered structure of the networks. The data structure can pick out (learn to represent) features at different scales or resolutions and combine them into higher-order features. For example from lines, to collections of lines to shapes.
The building block for neural networks are artificial neurons.
These are simple computational units that have weighted input signals and produce an output signal using an activation function.
Model of a Simple Neuron
You may be familiar with linear regression, in which case the weights on the inputs are very much like the coefficients used in a regression equation.
Like linear regression, each neuron also has a bias which can be thought of as an input that always has the value 1.0 and it too must be weighted.
For example, a neuron may have two inputs in which case it requires three weights. One for each input and one for the bias.
Weights are often initialized to small random values, such as values in the range 0 to 0.3, although more complex initialization schemes can be used.
Like linear regression, larger weights indicate increased complexity and fragility. It is desirable to keep weights in the network small and regularization techniques can be used.
The weighted inputs are summed and passed through an activation function, sometimes called a transfer function.
An activation function is a simple mapping of summed weighted input to the output of the neuron. It is called an activation function because it governs the threshold at which the neuron is activated and strength of the output signal.
Historically simple step activation functions were used where if the summed input was above a threshold, for example 0.5, then the neuron would output a value of 1.0, otherwise it would output a 0.0.
Traditionally non-linear activation functions are used. This allows the network to combine the inputs in more complex ways and in turn provide a richer capability in the functions they can model. Non-linear functions like the logistic also called the sigmoid function were used that output a value between 0 and 1 with an s-shaped distribution, and the hyperbolic tangent function also called tanh that outputs the same distribution over the range -1 to +1.
More recently the rectifier activation function has been shown to provide better results.
Neurons are arranged into networks of neurons.
A row of neurons is called a layer and one network can have multiple layers. The architecture of the neurons in the network is often called the network topology.
Model of a Simple Network
The bottom layer that takes input from your dataset is called the visible layer, because it is the exposed part of the network. Often a neural network is drawn with a visible layer with one neuron per input value or column in your dataset. These are not neurons as described above, but simply pass the input value though to the next layer.
Layers after the input layer are called hidden layers because that are not directly exposed to the input. The simplest network structure is to have a single neuron in the hidden layer that directly outputs the value.
Given increases in computing power and efficient libraries, very deep neural networks can be constructed. Deep learning can refer to having many hidden layers in your neural network. They are deep because they would have been unimaginably slow to train historically, but may take seconds or minutes to train using modern techniques and hardware.
The final hidden layer is called the output layer and it is responsible for outputting a value or vector of values that correspond to the format required for the problem.
The choice of activation function in he output layer is strongly constrained by the type of problem that you are modeling. For example:
Once configured, the neural network needs to be trained on your dataset.
You must first prepare your data for training on a neural network.
Data must be numerical, for example real values. If you have categorical data, such as a sex attribute with the values “male” and “female”, you can convert it to a real-valued representation called a one hot encoding. This is where one new column is added for each class value (two columns in the case of sex of male and female) and a 0 or 1 is added for each row depending on the class value for that row.
This same one hot encoding can be used on the output variable in classification problems with more than one class. This would create a binary vector from a single column that would be easy to directly compare to the output of the neuron in the network’s output layer, that as described above, would output one value for each class.
Neural networks require the input to be scaled in a consistent way. You can rescale it to the range between 0 and 1 called normalization. Another popular technique is to standardize it so that the distribution of each column has the mean of zero and the standard deviation of 1.
Scaling also applies to image pixel data. Data such as words can be converted to integers, such as the popularity rank of the word in the dataset and other encoding techniques.
The classical and still preferred training algorithm for neural networks is called stochastic gradient descent.
This is where one row of data is exposed to the network at a time as input. The network processes the input upward activating neurons as it goes to finally produce an output value. This is called a forward pass on the network. It is the type of pass that is also used after the network is trained in order to make predictions on new data.
The output of the network is compared to the expected output and an error is calculated. This error is then propagated back through the network, one layer at a time, and the weights are updated according to the amount that they contributed to the error. This clever bit of math is called the backpropagation algorithm.
The process is repeated for all of the examples in your training data. One of updating the network for the entire training dataset is called an epoch. A network may be trained for tens, hundreds or many thousands of epochs.
The weights in the network can be updated from the errors calculated for each training example and this is called online learning. It can result in fast but also chaotic changes to the network.
Alternatively, the errors can be saved up across all of the training examples and the network can be updated at the end. This is called batch learning and is often more stable.
Typically, because datasets are so large and because of computational efficiencies, the size of the batch, the number of examples the network is shown before an update is often reduced to a small number, such as tens or hundreds of examples.
The amount that weights are updated is controlled by a configuration parameters called the learning rate. It is also called the step size and controls the step or change made to network weight for a given error. Often small weight sizes are used such as 0.1 or 0.01 or smaller.
The update equation can be complemented with additional configuration terms that you can set.
Once a neural network has been trained it can be used to make predictions.
You can make predictions on test or validation data in order to estimate the skill of the model on unseen data. You can also deploy it operationally and use it to make predictions continuously.
The network topology and the final set of weights is all that you need to save from the model. Predictions are made by providing the input to the network and performing a forward-pass allowing it to generate an output that you can use as a prediction.
Deep Learning gets state-of-the-art results and Python hosts the most powerful tools.
Get started now!
PDF Download and Email Course.
Download your PDF containing all 14 lessons.
Get your daily lesson via email with tips and tricks.
There are decades of papers and books on the topic of artificial neural networks.
If you are new to the field I recommend the following resources as further reading:
In this post you discovered artificial neural networks for machine learning.
After reading this post you now know:
Do you have any questions about neural networks or about this post? Ask your question in the comments and I will do my best to answer it.
You can develop and evaluate deep learning models in just a few lines of Python code. You need:
Take the next step with 14 self-study tutorials and
7 end-to-end projects.
Covers multi-layer perceptrons, convolutional neural networks, objection recognition and more.
Ideal for machine learning practitioners already familiar with the Python ecosystem.
Bring Deep Learning To Your Machine Learning Projects
The post Crash Course On Multi-Layer Perceptron Neural Networks appeared first on Machine Learning Mastery.
You must understand your data in order to get the best results.
In this post you will discover 7 recipes that you can use in Python to learn more about your machine learning data.
Let’s get started.
Understand Your Machine Learning Data With Descriptive Statistics in Python
Photo by passer-by, some rights reserved.
This section lists 7 recipes that you can use to better understand your machine learning data.
Each recipe is demonstrated by loading the Pima Indians Diabetes classification dataset from the UCI Machine Learning repository.
Open your python interactive environment and try each recipe out in turn.
There is no substitute for looking at the raw data.
Looking at the raw data can reveal insights that you cannot get any other way. It can also plant seeds that may later grow into ideas on how to better preprocess and handle the data for machine learning tasks.
You can review the first 20 rows of your data using the head() function on the Pandas DataFrame.
# View first 20 rows import pandas url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] data = pandas.read_csv(url, names=names) peek = data.head(20) print(peek)
You can see that the first column lists the row number, which is handy for referencing a specific observation.
preg plas pres skin test mass pedi age class 0 6 148 72 35 0 33.6 0.627 50 1 1 1 85 66 29 0 26.6 0.351 31 0 2 8 183 64 0 0 23.3 0.672 32 1 3 1 89 66 23 94 28.1 0.167 21 0 4 0 137 40 35 168 43.1 2.288 33 1 5 5 116 74 0 0 25.6 0.201 30 0 6 3 78 50 32 88 31.0 0.248 26 1 7 10 115 0 0 0 35.3 0.134 29 0 8 2 197 70 45 543 30.5 0.158 53 1 9 8 125 96 0 0 0.0 0.232 54 1 10 4 110 92 0 0 37.6 0.191 30 0 11 10 168 74 0 0 38.0 0.537 34 1 12 10 139 80 0 0 27.1 1.441 57 0 13 1 189 60 23 846 30.1 0.398 59 1 14 5 166 72 19 175 25.8 0.587 51 1 15 7 100 0 0 0 30.0 0.484 32 1 16 0 118 84 47 230 45.8 0.551 31 1 17 7 107 74 0 0 29.6 0.254 31 1 18 1 103 30 38 83 43.3 0.183 33 0 19 1 115 70 30 96 34.6 0.529 32 1
You must have a very good handle on how much data you have, both in terms of rows and columns.
You can review the shape and size of your dataset by printing the shape property on the Pandas DataFrame.
# Dimensions of your data import pandas url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] data = pandas.read_csv(url, names=names) shape = data.shape print(shape)
The results are listed in rows then columns. You can see that the dataset has 768 rows and 9 columns.
(768, 9)
The type of each attribute is important.
Strings may need to be converted to floating point values or integers to represent categorical or ordinal values.
You can get an idea of the types of attributes by peeking at the raw data, as above. You can also list the data types used by the DataFrame to characterize each attribute using the dtypes property.
# Data Types for Each Attribute import pandas url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] data = pandas.read_csv(url, names=names) types = data.dtypes print(types)
You can see that most of the attributes are integers and that mass and pedi are floating point values.
preg int64 plas int64 pres int64 skin int64 test int64 mass float64 pedi float64 age int64 class int64 dtype: object
Descriptive statistics can give you great insight into the shape of each attribute.
Often you can create more summaries than you have time to review. The describe() function on the Pandas DataFrame lists 8 statistical properties of each attribute:
# Statistical Summary
import pandas
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
data = pandas.read_csv(url, names=names)
pandas.set_option('display.width', 100)
pandas.set_option('precision', 3)
description = data.describe()
print(description)
You can see that you do get a lot of data. You will note some calls to pandas.set_option() in the recipe to change the precision of the numbers and the preferred width of the output. This is to make it more readable for this example.
When describing your data this way, it is worth taking some time and reviewing observations from the results. This might include the presence of “NA” values for missing data or surprising distributions for attributes.
preg plas pres skin test mass pedi age class count 768.000 768.000 768.000 768.000 768.000 768.000 768.000 768.000 768.000 mean 3.845 120.895 69.105 20.536 79.799 31.993 0.472 33.241 0.349 std 3.370 31.973 19.356 15.952 115.244 7.884 0.331 11.760 0.477 min 0.000 0.000 0.000 0.000 0.000 0.000 0.078 21.000 0.000 25% 1.000 99.000 62.000 0.000 0.000 27.300 0.244 24.000 0.000 50% 3.000 117.000 72.000 23.000 30.500 32.000 0.372 29.000 0.000 75% 6.000 140.250 80.000 32.000 127.250 36.600 0.626 41.000 1.000 max 17.000 199.000 122.000 99.000 846.000 67.100 2.420 81.000 1.000
On classification problems you need to know how balanced the class values are.
Highly imbalanced problems (a lot more observations for one class than another) are common and may need special handling in the data preparation stage of your project.
You can quickly get an idea of the distribution of the class attribute in Pandas.
# Class Distribution
import pandas
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
data = pandas.read_csv(url, names=names)
class_counts = data.groupby('class').size()
print(class_counts)
You can see that there are nearly double the number of observations with class 0 (no onset of diabetes) than there are with class 1 (onset of diabetes).
class 0 500 1 268
Correlation refers to the relationship between two variables and how they may or may not change together.
The most common method for calculating correlation is Pearson’s Correlation Coefficient, that assumes a normal distribution of the attributes involved. A correlation of -1 or 1 shows a full negative or positive correlation respectively. Whereas a value of 0 shows no correlation at all.
Some machine learning algorithms like linear and logistic regression can suffer poor performance if there are highly correlated attributes in your dataset. As such, it is a good idea to review all of the pair-wise correlations of the attributes in your dataset. You can use the corr() function on the Pandas DataFrame to calculate a correlation matrix.
# Pairwise Pearson correlations
import pandas
url = "http://ift.tt/1Ogiw3p;
names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class']
data = pandas.read_csv(url, names=names)
pandas.set_option('display.width', 100)
pandas.set_option('precision', 3)
correlations = data.corr(method='pearson')
print(correlations)
The matrix lists all attributes across the top and down the side, to give correlation between all pairs of attributes (twice, because the matrix is symmetrical). You can see the diagonal line through the matrix from the top left to bottom right corners of the matrix shows perfect correlation of each attribute with itself.
preg plas pres skin test mass pedi age class preg 1.000 0.129 0.141 -0.082 -0.074 0.018 -0.034 0.544 0.222 plas 0.129 1.000 0.153 0.057 0.331 0.221 0.137 0.264 0.467 pres 0.141 0.153 1.000 0.207 0.089 0.282 0.041 0.240 0.065 skin -0.082 0.057 0.207 1.000 0.437 0.393 0.184 -0.114 0.075 test -0.074 0.331 0.089 0.437 1.000 0.198 0.185 -0.042 0.131 mass 0.018 0.221 0.282 0.393 0.198 1.000 0.141 0.036 0.293 pedi -0.034 0.137 0.041 0.184 0.185 0.141 1.000 0.034 0.174 age 0.544 0.264 0.240 -0.114 -0.042 0.036 0.034 1.000 0.238 class 0.222 0.467 0.065 0.075 0.131 0.293 0.174 0.238 1.000
Skew refers to a distribution that is assumed Gaussian (normal or bell curve) that is shifted or squashed in one direction or another.
Many machine learning algorithms assume a Gaussian distribution. Knowing that an attribute has a skew may allow you to perform data preparation to correct the skew and later improve the accuracy of your models.
You can calculate the skew of each attribute using the skew() function on the Pandas DataFrame.
# Skew for each attribute import pandas url = "http://ift.tt/1Ogiw3p; names = ['preg', 'plas', 'pres', 'skin', 'test', 'mass', 'pedi', 'age', 'class'] data = pandas.read_csv(url, names=names) skew = data.skew() print(skew)
The skew result show a positive (right) or negative (left) skew. Values closer to zero show less skew.
preg 0.901674 plas 0.173754 pres -1.843608 skin 0.109372 test 2.272251 mass -0.428982 pedi 1.919911 age 1.129597 class 0.635017
This was just a selection of the most useful summaries and descriptive statistics that you can use on your machine learning data for classification and regression.
There are many other statistics that you could calculate.
Is there a specific statistic that you like to calculate and review when you start working on a new data set? Leave a comment and let me know.
This section gives you some tips to remember when reviewing your data using summary statistics.
Python and scikit-learn are the rising platform among professional data scientists for applied machine learning.
PDF and Email Course.
Download your PDF containing all 14 lessons.
Get your daily lesson via email with tips and tricks.
In this post you discovered the importance of describing your dataset before you start work on your machine learning project.
You discovered 7 different ways to summarize your dataset using Python and Pandas:
Do you have any questions about Python, Pandas or the recipes in this post? Leave a comment and ask your question, I will do my best to answer it.
Finally understand how to work through a machine learning problem, step-by-step in the new Ebook:
Machine Learning Mastery with Python
Take the next step with 16 self-study lessons covering data preparation, feature selection, ensembles and more.
Includes 3 end-to-end projects and a project template to tie it all together.
Ideal for beginners and intermediate levels.
Apply Machine Learning Like A Professional With Python
The post Understand Your Machine Learning Data With Descriptive Statistics in Python appeared first on Machine Learning Mastery.
Entradas
Comentarios
